Topvex, exactly what you need!TopvexAir Handling Units
Wide range of compact and standardised air handling units for easy installation and fast delivery.
EASY.
Selection, installation and intuitive control system
QUICK.
Wide range of standardised units with fast delivery
COMPACT.
Minimum space required with efficent performance
?_=1701872179041)
Topvex FCU
Air Handling Units · Wide range of compact false ceiling units (FCU) with wireless communication.
Airflow range: 400 up to 3,000 m³/h
High energy efficiency and space-saving design
Easy access to filters for simple maintenance
?_=1701872263813)
Topvex FSU
Air Handling Units · Wide range of compact floor standing units (FSU) with complete control system.
Airflow range: 360 up to 9,500 m³/h
High energy efficiency and space-saving design
Rotary, Counterflow and outdoor version.
)
We understand your challenges
High energy efficiency, space-saving designs, and a wide standard range ensure the consultant can meet the project specifications. A powerful selection tool and project specific documentation make the job even easier.
For the installer, Topvex AHU’s are easy to buy and transport, with short lead times and plug-and-play installation. Configuration Wizard ensures easy start-up.
Low overall operating costs, reliable operation and minimum maintenance mean peace-of-mind for the building owner or manager.
Your ventilation project starts with our selection tool
Systemair’s configurator for Topvex
)
Select and configure your Topvex unit with a few simple commands in our web based Topvex configurator.
Using the downloadable Systemair Topvex plugin, installed on your computer, you can easily export the BIM model you get from the configurator to your CAD program. You get all the data from the calculation, such as airflow, precise dimensions, sound data, and more.
With our plugin you can easily access the configurator directly from your CAD program - with a single click via the Systemair icon.
The Systemair configurator at a glance
Select, design and configure your air handling units easily.
Transfer the BIM data through the plugin for Revit, AutoCAD and MagiCAD.
Create and download all relevant documentation.
Our plugin is available for Revit, AutoCAD and MagiCAD and can be downloaded from our website.
Configure a suitable unit and export it to your BIM model. If parameters, such as airflow, change during the project, the CAD program will detect it.
A dialogue box will then open asking you to recalculate the unit. Click OK in the dialogue box and the configurator will reopen to perform a new calculation with the new airflow.
Send the result back to the CAD program and you have correct data for the unit in your BIM model again.
Topvex in a nutshell
Key features
)
Topvex air handling units stem from our ambition to provide an integrated solution that is easy to configure to suit customer needs, while ensuring easy installation and fast delivery.
High-performance casing: Durable MgZn casing with C5 corrosion resistance
Panels with 50 mm insulation
Heat exchangers with low pressure drop and high heat recovery >80%
Factory tested
Now available with cooling and heating possibilities: Systemair Fusion
)
Experience ultimate control with Systemair Access – available for all Topvex air handling units
Systemair Access is a complete control system for air handling units, making advanced technology easily accessible. It allows operators to optimise ventilation performance, helping them to create the perfect indoor climate. Using your Topvex air handling unit more effectively will help you reduce energy consumption and save money.
Intuitive, easy-to-navigate menus will help you create the perfect indoor climate.
A plug-and-play concept, reducing installation, set-up, and start-up time, quickly putting you in full control.
Modbus communication to all internal components simplifies cabling and wiring inside the unit.
Multiple units can be connected to a cloud service for complete overview and accessibility.
For Topvex false ceiling units, Systemair Access is now available with wireless connection
)
Case Study: Franska Bukten, Sweden
Systemair delivered Topvex Air Handling Units with integrated smoke bypass to an residential building in Stockholm. The reason for this? Their compact design, energy efficiency, other features and us as a reliable partner.
